Sinotruk SITRAK C7H 8×4 Dump Truck

The Sinotruk SITRAK C7H 8×4 Dump Truck is a heavy-duty off-road vehicle co-developed with MAN, featuring a German-engineered MC series diesel engine (350–440 hp), a robust 8×4 chassis, and a high-strength dump body with a heaped capacity of 20–32 cubic meters. Designed for mining, quarrying, and large-scale construction projects, it offers reliable hydraulic lifting, heavy-duty suspension, and dual-circuit air brakes, making it a popular export choice for demanding markets in Southeast Asia, Africa, and the Middle East.



What information should you let me know if I want to get a quote?

Please let us know your purpose, road condition, type of cargo, tons of your cargo, size of trailer, quantity, etc.

You provide the information, more accurate model and price.



What can you buy from us?

Dump trailer, flatbed trailer, full trailer, rail-plate trailer, grille trailer, container trailer, tank trailer, vehicle transporter, van trailer, all kinds of special vehicles, dump truck, tractor-trailers, semi-trailers, self-tilting trucks, trailer parts,Electric Cargo tricycle etc.



How to control quality?

We set up all process inspection and quality control standard, include raw materials, production process, finished products.Advanced equipment and standard inspection process ensure the quality.

contact us

Consult Now

1. Overview

The SITRAK C7H 8×4 dump truck is a heavy-duty tipper developed by Sinotruk (China National Heavy Duty Truck Group) in collaboration with Germany's MAN Truck & Bus AG. As the flagship product of Sinotruk's SITRAK series, this vehicle integrates German MAN's advanced technology in cab design, chassis, axles, and engines. Built with the same product design, production assembly processes, testing protocols, and supplier system as MAN trucks, the C7H delivers world-class reliability for demanding applications such as construction, mining, and bulk material transport.

2. Key Features

2.1 High Reliability – German MAN Technology

Feature	Description
German MAN Technology	Full introduction of MAN TG series vehicle technology, identical product design and production assembly processes
German Standard Quality	Production conformity management, testing & validation, product release all follow German MAN standards
Global Supplier System	Synchronized parts purchasing system with MAN ensures high-quality components

2.2 Powerful & Efficient Engine – MC Series

Feature	Description
Engine Series	MC11 / MC13 (Derived from German MAN technology, improved in China)
Power Range	310 – 540 HP
Low Fuel Consumption	Wide area of low fuel consumption and large torque; minimum specific fuel consumption only 186 g/kW·h
Long Service Interval	Engine oil change interval up to 80,000 km
B10 Life	1.5 million kilometers

2.3 High Safety Standards

Safety Feature	Function
ECE R29 Cab Certification	Cab rigidity and strength meet international standards; doors can still open freely even after cab deformation
EVB (Engine Valve Brake)	Reduces brake frequency on long downhill slopes
Front Disc Brakes	Standard on front axle; improves braking efficiency
ABS+ASR+EBL+TPM	Comprehensive electronic safety system for enhanced driving safety
Electronic Management (BCU+VCU)	Dual electronic control units ensure driving safety
High Full-Metal Bumper	Added protection for front-end components

2.4 High Comfort & Spacious Cab

Comfort Feature	Description
Cab Options	C7H-P (749mm single bunk) / C7H-M (525mm single bunk)
Four-Point Suspension	Optimized cab suspension system for reduced vibration
Air Suspension Seat	Adjustable lumbar support for driver comfort
Slatted Design Bunk	Comfortable sleeping area for rest during long shifts
Large Storage Space	Ample space for toolboxes and personal items
Automatic Air Conditioning	Optional, for climate control comfort

3. Technical Specifications

3.1 Vehicle Parameters

Parameter	Specification
Drive Type	8×4
Steering	Left-hand drive (standard)
Gross Vehicle Weight (GVW)	31,000 kg
Curb Weight	Approx. 15,500 kg
Rated Load Capacity	Approx. 15,370 kg
Max Speed	75 – 101 km/h
Max Gradeability	35%

3.2 Dimensions

Parameter	Short Wheelbase	Long Wheelbase
Overall Length	9,572 mm	10,752 – 11,832 mm
Overall Width	2,550 mm	2,550 mm
Overall Height	3,500 mm	3,460 – 3,910 mm
Wheelbase	1,950+2,525+1,350 mm	1,950+3,225+1,350 mm
Front Track	2,041 mm	2,041 mm
Rear Track	1,830 mm	1,830 mm
Approach Angle	19°	19°
Departure Angle	24°	—

3.3 Engine Specifications

Parameter	MC11	MC13
Displacement	10.518 L	12.42 – 12.419 L
Max Power	324 – 327 kW (440 HP)	400 kW (540 HP)
Max Torque	2,100 N·m	2,500 N·m
Torque Range	1,000 – 1,400 rpm	1,050 – 1,350 rpm
Emission Standards	Euro VI (China VI)	Euro III – Euro V
Min Specific Fuel Consumption	—	186 g/kW·h

3.4 Chassis & Drivetrain

Component	Specification
Transmission	HW25712XS (12 forward, 2 reverse), AMT optional
Front Axle	HR9 (9.5T) – Dual front axles
Rear Axle	AC16 (16T) – Dual rear axles
Axle Ratio	5.45
Frame	8+8mm double-layer frame
Suspension	11/11/12 leaf springs
Clutch	Φ430
Fuel Tank	400L – 800L aluminum alloy

3.5 Tires

Parameter	Specification
Tire Size	12.00R20 / 12R22.5 / 13R22.5 / 315/80R22.5
Tire Count	12 (10+2 spare)

3.6 Body (Tipper) Specifications

Parameter	Specification
Body Volume	18 – 28 cubic meters (customizable)
Body Material	Carbon steel plates
Lifting Method	Front hydraulic lifting system
Body Length	Up to 8,800 mm
Body Width	2,350 – 2,380 mm
Body Height	1,500 – 1,580 mm

4. Model Configuration Comparison

Feature	Standard Model	Long Wheelbase Model	High-Power Model
Model	ZZ3316N326MF1	ZZ3316N406MF1	ZZ3316N486HE1
Wheelbase	1,950+2,525+1,350 mm	1,950+3,225+1,350 mm	Extended
Engine	MC11.44-60 (440 HP)	MC11.44-60 (440 HP)	MC13.54-50 (540 HP)
Emission	Euro VI	Euro VI	Euro V
Body Length	7.8 m	Customizable	Customizable
Price (approx.)	¥445,000	¥445,000	¥458,000
Best For	Urban construction, standard dump operations	Highway transport, longer hauls	Heavy mining, extreme conditions

5. Key Technologies

5.1 Engine Technology

Technology	Benefit
High-Pressure Common Rail	Precise fuel injection for optimal combustion
EGR+SCR	Meets stringent emission standards while maintaining fuel efficiency
Low-Friction Design	Reduced internal friction improves fuel economy
High Torque at Low RPM	1,000-1,400 rpm torque range provides excellent pulling power

5.2 Safety Technology

Technology	Function
EVB (Exhaust Valve Brake)	Engine braking system for downhill control
ABS 4S/4M	Advanced anti-lock braking system with 4 sensors/4 modulators
ASR (Anti-Slip Regulation)	Prevents wheel spin on slippery surfaces
EBL (Electronic Brake Light)	Automatic brake light activation during engine braking
TPM (Tire Pressure Monitoring)	Real-time tire pressure monitoring

6. Cab Features

Feature	C7H-P	C7H-M
Roof Type	High-roof flat top	Standard roof
Bunk Width	749mm single bunk	525mm single bunk
Sleeper Count	Double sleeper	Single sleeper
Air Conditioning	Standard	Optional
Tilt Capability	Forward-tilting for engine access	Forward-tilting

Common Cab Features:

Four-point cab suspension
Air suspension driver seat with lumbar support
Ergonomic dashboard and switch layout
Power windows
Optional 360° camera system

7. Applications

Application	Why C7H 8×4
Urban Construction / Earthmoving	High maneuverability, 8×4 traction, durable dump body
Mining / Quarry Operations	Heavy-duty axles (16T dual rear), high torque for steep grades
Large-Scale Infrastructure	High payload (31T GVW), long wheelbase options for stability
Bulk Material Transport (sand, gravel, coal)	18-28m³ body volume, efficient hydraulic lifting system
Heavy Industrial Logistics	Robust chassis, high reliability for continuous operation

8. Buying Guide

8.1 Key Selection Factors

Factor	Consideration
Application Type	Urban construction vs. mining vs. long-haul material transport
Required Body Volume	18-28m³ depending on material density and local regulations
Emission Standards	Euro III-V for export; Euro VI for China domestic use
Terrain Conditions	Standard transmission for flat terrain; AMT for mixed/hilly terrain
Wheelbase Selection	Short wheelbase for maneuverability; long wheelbase for stability at speed
Budget	Prices range from ¥445,000 to ¥458,000 (approx. $61,000-$63,000 USD)

8.2 Customization Options

Customizable Item	Options
Body Size	Length, width, height adjustable
Body Volume	18 – 28 cubic meters
Color	Custom paint (company logo available)
Transmission	Manual or AMT (ZF available)
Tire Specification	Multiple options for different terrains

9. Delivery & Service

Item	Details
Lead Time	20 – 45 days (depending on configuration and order quantity)
Minimum Order	1 unit
Shipping	RORO / Flat rack / Container
Warranty	Standard manufacturer warranty (varies by component)
Payment Terms	T/T, L/C at sight, 30/60/90 days L/C
Certification	ISO, CCC, SGS, BV available
Service Network	Global service support through Sinotruk's international network
Documentation	Commercial invoice, packing list, bill of lading, certificate of origin, owner's manual


